Description
The T5074 delivers dependable power and strong loader performance with a reliable Yanmar diesel engine. It is simple to maintain and built for serious work, focusing on durability and useful capability.
Engine
Engine Manufacturer
Yanmar 4TNV98CT-PKTF
Type
Turbocharger
Engine power
71.5 hp | 53.3 kW
PTO power
60.2 hp | 44.8 kW
Rated engine speed
2400 rpm
No. of cylinders
4
Displacement
202.5 cu. in. | 3319 cc
Air cleaner
PowerCore type
Alternator
12V, 70A
Fuel system
CRDI
Drive Line
Transmission type
Power shuttle
No. of speeds
F12 x R12
Max. traveling speed
13.49 mph | 21.72 km/h
Brakes
Wet disc
Steering
Hydrostatic
Clutch
Wet multi-plate
Measurements
Overall length with 3-point hitch
148.1 in. | 3764 mm
Overall width
81.4 in. | 2068 mm
Wheelbase
84.6 in. | 2150 mm
Height to top of ROPS
106.8 in. | 2715 mm
Min. ground clearance
18.3 in. | 465 mm
Min. turn radius with brakes
145.6 in. | 3700 mm
Min. turn radius without brakes
169.3 in. | 4300 mm
Weight with ROPS
5463 lb | 2478 kg
